Top Type Hydraulic Breaker
CSW Machinery Top type hydraulic breaker, with the excavator installation point is relatively high, the direct force is large, and the advantages in vertical strike are obvious. For horizontal and trench working surfaces, such as building demolition, tunnels, underwater, etc., the tower type hydraulic breaker has a relatively large working Angle and is more flexible in operation.
Hydraulic Breakers: Excavators and Construction Sites for Any Job
No matter what the job site requirements are, CSW Machinery can provide the perfect breaker for the job. Whether used for hard rock
or urban building demolition, or concrete pavements, our breakers get the job done easily and efficiently.
CSW Machinery offers OEM high quality hydraulicbreakers of Soosan series, Furukawa Series, Altas Copco Series, etc.
They are made into top type, side type, box silent type, skid steer type, backhoe loader type.
| Main Specifications | |||||||||||||
| Soosan Series ( most commonly used size ) | |||||||||||||
| Model | SB10 (PL400) | SB20 (PL450) | SB30 (PL530) | SB40 (PL680) | SB45 (PL800) | SB50 (PL1000) | SB60 (PL1250) | SB70 (PL1350) | SB81 (PL1400) | SB121(1550) | SB131 (1650) | SB151 (PL1750) | SB195 (PL1950) |
| Machine (Ton) | 0.8~2.5 | 1.2~3.0 | 2.5~4.5 | 4.0~7.0 | 7.0~14 | 11~16 | 15~18 | 16~21 | 18~26 | 28~35 | 35~45 | 45~55 | 50~90 |
| Tool OD (mm) | 40 | 45 | 53 | 68 | 85 | 100 | 125 | 135 | 140 | 155 | 165 | 175 | 195 |
| Impact rate (bpm） | 800~1400 | 700~1200 | 600~1100 | 500~900 | 400~800 | 350~700 | 350~650 | 350~600 | 350~500 | 300~450 | 250~350 | 250~350 | 180~220 |
| Furukawa Series(most commonly used size) | Atlas Copco Series | ||||
| Model | 15G (1500G） | 20G (2000G) | 30G (3000G) | 40G (4000G) | HB2200 (ATM1500) |
| Machine (Ton) | 12~18 | 18~25 | 25~33 | 35~45 | 18~26 |
| Tool OD (mm) | 120 | 135 | 150 | 160 | 135 |
| Impact rate (bpm） | 350~-650 | 350~600 | 300~450 | 300~400 | 340~650 |
Box Type Hydraulic Breaker
Top Type Hydraulic Breaker
Side Type Hydraulic Breaker
Skid Steer Hydraulic Breaker
Backhoe type Hydraulic Breaker
DX340-30G
DX210-SB81
EC210-20G
EX120-SB50
New Holland E205-SB81
CAT330-SB121
SB151
SDLG 210-20G
SK135-SB50
U57-SB40
PC130-WB400
ZX200-WB1400
DX220-20G
DX35-SB30
DX60-SB40
SB30-EX55
DX210-SB81
ZX200-SB81
ZX280-SB121
SHY140
CAT315-WB1400
ZX20-SB10
CAT320D-20G
PC300-30G
CAT308E
PC200-SB81A
R60-SB40
R60-SB40
R80-SB43
R450-SB131
CAT305-SB40
SY60C-SB50
CAT307-SB50
LIUGONG 912-SB50
ZX200-SB81
CAT330-SB121
PC500-SB151
SDLG240-20G
SDLG60-SB40
SK20-SB10
SY215-SB81
SWE60E-WB680
ZX70-5G-WB750
ZX130-WB1400
EC35-WB530
CAT323-SB81A
CAT305.5-PL680
PC120-WB1000
SK75SR-PL750
SK100-PL1000
PC100-PL1000
ZX80-SB43
JD75-PL750
